SICME MOTORI R4740175B

IN STOCK & READY TO SHIP
Manufacturer: SICME MOTORI
Part Code: R4740175B
Component: Direct Current Motor Rated power: 500 kW Rated speed: 1000 rpm / 1350 rpm Armature voltage: 400 V Armature current: 1352 A Field voltage: 250 V Field current: 10.1 A / 6.8 A Frame size: NP 355 KS 7 PVA Mounting type: B3 Duty cycle: S1 Insulation class: HDTH Protection type: 23 Mounting type B3: for Ensenada plant, double shaft, second floor, SICMEMOTORI R4740175B Separately excited motor Weight: 3000 kg Moment of inertia (J): 15.9 kgm² N: 0367/99/1 Armature resistance: 0.014 Ohm at 115 ºC Field resistance: 22.23 Ohm at 115 ºC Twin parallel brushes type EG319PI Brush dimensions: 25 x 40 x 64 mm With built-in blower, SICME model 1471701010 Driven by three-phase flanged motor type AK132SA-B5-5.5kW-1470 rpm Note: Reception will occur subject to installation and in-line testing. The supplier must collect in-line data to ensure full compatibility of both motor and blower. Use: Tensioning for LAI SN leveler and EDA pickling accumulator cart Brand: SICME MO
SICME MOTORI R4740175B Direct Current Motor Rated power: 500 kW Rated speed: 1000 rpm / 1350 rpm Armature voltage: 400 V Armature current: 1352 A Field voltage: 250 V Field current: 10.1 A / 6.8 A Frame size: NP 355 KS 7 PVA Mounting type: B3 Duty cycle: S1 Insulation class: HDTH Protection type: 23 Mounting type B3: for Ensenada plant, double shaft, second floor, SICMEMOTORI R4740175B Separately excited motor Weight: 3000 kg Moment of inertia (J): 15.9 kgm² N: 0367/99/1 Armature resistance: 0.014 Ohm at 115 ºC Field resistance: 22.23 Ohm at 115 ºC Twin parallel brushes type EG319PI Brush dimensions: 25 x 40 x 64 mm With built-in blower, SICME model 1471701010 Driven by three-phase flanged motor type AK132SA-B5-5.5kW-1470 rpm Note: Reception will occur subject to installation and in-line testing. The supplier must collect in-line data to ensure full compatibility of both motor and blower. Use: Tensioning for LAI SN leveler and EDA pickling accumulator cart Brand: SICME MO - Genuine SICME MOTORI Industrial Spare Part
Click to inspect photo
Guaranteed Genuine Part • 12 Months Warranty • Fast Dispatch from Houston, TX
US Domestic Partner: 1 PO in USD • Eliminates overseas vendor wire prepayments
All-Inclusive DDP Pricing: Factory supply, customs clearance & transatlantic freight included
Houston Verified: 100% bench tested • 12-Month AMS Domestic Warranty
